KLAS Telecom Voyager 6 Tactical Chassis 500W, 12VDC/28VDC Out P/N KLAS-VOY-CHAS6
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| Brand | KLAS |
| Rack Unit Width | 16 in |
| Type | Chassis |
| Rack Depth | 14 in |
| MPN | KLAS-VOY-CHAS6 |
| Rack Unit Height | 9.5 in |
KLAS Telecom Voyager 6 Tactical Chassis P/N KLAS-VOY-CHAS6 The Voyager 6 is a six slot chassis designed for mobile applications. The chassis is compatible with the Standardized A-Kit Vehicle Envelope (SAVE) specification and the SINCGARS MT-6352. Each of the six slots can accommodate a standard Voyager form factors.Voyager 6 - KEY FEATURES: Support for up to six Voyager modules and radio brackets in standard Voyager form factors28 VDC power input to MIL-STD-1275 for vehicle installationsMechanically isolated chassis with anti-vibration mounts and separate failsafeSupports any 12 VDC or 28 VDC Voyager modules including 3rd party radios mounted in Klas radio bracketsCompatible with Standardized A-Kit / Vehicle Envelope (SAVE) specifications which creates a significant reduction in time and resources when integrating into existing vehiclesChassis can be removed from the vehicle mount for ease of installation and maintenanceOptional external PSU (200W & 600W) available for use in desktop environmentOptional transit case availablePHYSICAL SPECIFICATIONS:14.2” x 16” x 9.45” (360 x 406 x 240mm) 43 lb / 19.5 Kg ELECTRICAL SPECIFICATIONS: DC Input (M55181/2-01): • 20 - 33 VDC Input (28 Amp Max.) DC Output (M55181/4-01): • The DC output is the input power looped DC Slot Output • 12 VDC or 28 VDC (dependant on module installed in each slot) Total power available 500WEach slot can provide 12 VDC at 10 Amps Each slot can provide 28 VDC at 2.5 Amps (total 28 VDC power budget is 70 W)
