ANYCUBIC Photon Mono 2 Resin 3D Printer 6.6″ 4K+ LCD Screen / Wash & Cure lot
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Brand | ANYCUBIC |
| Model | Photon MONO 2 |
| MPN | PM2A0BK |
| Interface | USB 2.0 |
| Features | DIY Kit |
| Manufacturer Warranty | 1 year |
| 3D Technology | LCD |
| Control Panel | 2.8''TFT touch-control |
| Maximum Print Size | 165*89*143mm |
| Print Inches | 5.6'' x 3.5'' x 6.5'' |
| Maximum Resolution | 4096*2560 |
| Printing Speed | 60mm/h |
| Light Transmittance | 3.5%-4.5% |
| Contrast Ratio | 300:1 |
| Service Life | 2,000h |
| Country/Region Of Manufacture | China |
| Item Length | 235mm |
| Item Width | 229mm |
| Item Height | 390mm |
| Unit Type | Unit |
ANYCUBIC Photon Mono 2 Technical Specifications ● Removable Cover: Effectively blocks UV radiation● Z Axis: Double liners with 10 μm accuracy● Build Platform: Laser engraving aluminum alloy● Exposure Screen: 6.6" monochrome (4,096 x 2,560 px)● Oversized Protection Film: Replaceable anti-scratch film● Light Source: Parallel matrix upgrade light source● Power Supply: 48W rated power● Control Panel: 2.8''TFT touch-control● Data Input: USB Type-A 2.0● Machine Leveling: 4-point manual leveling● Printing Speed: ≤ 5cm/hr. 1.97in/hr● Printing Dimensions: 165 x 89 x 143 mm/6.5 x 3.5 x 5.6 inches (HWD)● Machine Size: 390 x 229 x 235 mm / 15.4 x 9.01 x 9.5 inches (HWD)● Machine Weight: 4kg / 8.8lb Bigger and Higher Resolution Photon Mono 2 uses a 6.6-inch monochrome LCD screen with a resolution of 4096*2560, which can display the models' tiny details. Ultra-Large Screen Protector The ultra-large scratch-resistant screen protector helps to prevent screen scratches and resin penetration. With up to 95% light transmittance, it can fully protect the LCD screen while ensuring printing accuracy. Upgraded LighTurbo Matrix The upgraded LighTurbo matrix provides a stable and uniform parallel light source, thus effectively reducing the layer lines and eliminating grid lines. Therefore, Photon Mono 2 can make the model details more vivid and make the model surface delicate and smooth. Models Display Parts List Funnel Gloves Mask Screen protector Platform Power adaptor Resin vat Levelling paper Scraper USB drive Tool set ANYCUBIC Wash and Cure 3 Larger Size for Upgraded Capacity Compared to Anycubic Wash & Cure 2.0, the Anycubic Wash & Cure 3 has an impressive 100% increase in cleaning basket capacity, now at 3 liters. The total volume of the cleaning bucket has been expanded to 4 liters. This makes it perfectly tailored for LCD (light-curing) 3D printers with a size of 7.3 inches or less.The curing size has increased by 15%, up to 160*180 millimeters, to accommodate larger and more models for single post-processing session. Localized Strengthening, Uniform Curing The "Innovative Flexicure Gooseneck Light Design" increases the energy value by 30,000uW/cm² within a 1-3 cm irradiation range, significantly strengthening the curing effect on subtle areas such as the top of models and the hem of garments. By adopting a brand new arrangement of light beads and lens light source, Anycubic Wash & Cure 3's curing uniformity has been enhanced by 20% compared to its predecessor 2.0. This results in a more thorough and comprehensive curing of the entire model. Dual-layer Design, IPA Saving The double-layered PP material cleaning basket is designed to support simultaneous cleaning with the platform. It features two adjustable heights at 100mm and 165mm, providing flexibility to accommodate printing platforms ranging from 5.9 inches to 7.3 inches. This design maximizes the efficiency of IPA usage. Simple Operation, Quiet and Efficient Cleaning and curing dual modes, easily selected with one click; Enhanced Gooseneck light curing mode can be easily toggled on and off with one click. Infinite rotary knob control, adjustable from 1 to 30 minutes at will. Through a more sealed structural design and software optimization, the noise interference generated during cleaning and curing is reduced[1], creating a quieter and more comfortable working environment. [1] Measured by Anycubic Laboratory the maximum sound < 65dB in the operating state of the machine. Models Display In The Box ANYCUBIC Wash and Cure 3 Plus Partial Enhanced The innovative Flexicure gooseneck lights design increases the energy value by 30,000uW/cm² in the 1~3cm irradiation range, which greatly enhances the curing effect on details such as the top of the model and the figure's skirt. Overall Curing Adopting a brand-new arrangement of lamb beads combined with a lens light source, it offers a 20% improvement in curing uniformity compared to wash&cure plus, thus 3d models can achieve better quality and consistency after curing. On Jun 6, 2024 at 20:44:10 PDT, seller added the following information:
